結構優化技術

Structural optimal technology

技術內容

Technology and method

l結構拓?fù)鋬?yōu)化

Structural topology optimization

l有限元優化

Optimizationwith finite element method

l機構布局優化

Mechanism layout optimization

?

應用案例

Projects

l履帶起重機頂節臂結構拓?fù)鋬?yōu)化

Structural topology optimization for top boom of crawler crane

l履帶起重機腰繩長度與位置優化

Optimization for crawler crane’s auxiliary bracing

l箱型伸縮臂截面拓?fù)鋬?yōu)化

Topology optimization for telescoping boom’s section

l四連桿門座起重機變幅機構優化

Optimization for four-bar linkage luffing mechanism of portal crane

l履帶起重機上車鉸點優化

Optimization?for hinge position on superstructure of crawler crane

l橋式起重機主梁結構優化

Structural optimization for main girder of overhead travelling crane

?

圖片

履帶起重機頂節臂結構拓?fù)鋬?yōu)化

?

?

履帶起重機腰繩長度與位置優化

?

?

?

箱型伸縮臂截面拓?fù)鋬?yōu)化

??

?

四連桿門座變幅機構優化

橋式起重機主梁結構優化
